Live Gamer HD is a PCIe capture card made for hardcore PC gamers. The hardware encoder records and streams smooth, synced, and lag-free 1080p gameplay at the press of a button.
Picture Perfect
Live Gamer HD records at bitrates of up to 60 Mbps, indulging you and your viewers the pleasure of true-to-the-original picture quality.
Savior of CPU
The advanced H.264 encoder in Live Gamer HD takes the burden off your CPU. Your games will now run smoother, your videos will be lag-free, and kept at more manageable sizes too.
Tap and Go!
A simple tap is all it takes to start your recording or streaming session in our bundled software RECentral. The Hot Button also acts as an indicator. It flashes red when a session is live, so you'll know in a glance whether it's OK to go back to your normal self.
Your Choice of Application and Platform
Live Gamer HD works with any DirectShow compliant streaming application such as XSplit or OBS, and broadcasts to YouTube, Twitch, or Ustream right out of the box. You also have the privilege to record and stream with our exclusive RECentral.
- Technical Specifications
- • Interface:PCI-Express x1 / USB (Hot Button)
• Video Input:HDMI
• Video Output (Pass-Through):HDMI
• Audio Input:HDMI / 3-Pole 3.5 mm Jack
• Audio Output (Pass-Through):HDMI / 3-Pole 3.5 mm Jack
• Max Pass-Through Resolutions:1080p60
• Max Record Resolutions:1080p30
• Supported Resolutions (Video input):1080p, 1080i, 720p, 576p, 480p, 480i
• Record Format:MPEG 4 (H.264+AAC) / Supports hardware encoding
• Dimension (W x D x H):123 x 104 x 22 mm (4.8 x 4.1 x 0.9 in)
• Weight:102.5 g (3.6 oz)
Notes:
1. LGHD does not support viewing/recording/streaming of HDCP protected signals
- System Requirements(For dedicated streaming PC)
- Operating sytem: Windows® 10 / 8.1 / 7 For 1080p30 Intel® Core™ 2 Duo 2.4 GHz / AMD Athlon 64 X2 2.8 GHz
VGA card supporting DirectX 9.0c
512MB RAM
Notes:
1. Discrete graphics card recommended for HD video capturing
- What's in the box
- • Live Gamer HD 2 (C985)
• Hot button
• HDMI cable
• HDMI to DVI cable
• DVI to HDMI adapter
• 3.5 mm audio cable
• Quick guide
ถามและตอบ
Audio
Micro SD Card
VRR
Troubleshooting
疑難排解
Settings
MAC M1
How do I start to use the Device
Software Usability
Hardware usability
Features/Functions
OBS
Chromebook
Windows
Mac OS
セットアップ
セットアップ・仕様
接続機器・設定
4K / HDR対応
VRR対応
音声端子
仕様
仕様・ソフト
仕様・ソフト（コントロール部）
仕様・ソフト（ミキサー部）
ストレージ
（PCモード）仕様・ソフト
（単体モード）仕様・設定
録画
配信
実況
再生
再生・編集
編集
Mac対応
相性
動画編集ソフト
ファイル管理
アップロード
ソフト
購入前のお問合せ
F225本体・付属品
セットアップ、Wi-Fi接続
テレビ視聴、設定画面
録画、予約録画、録画再生
アプリ
番組表
通信
設定
その他
困った時は
更新
EOL All
Streaming
Capturing
All Topics
Recording
Storage
Indicator Light
File management
Voice Commentary
GameMate
Upload
Playback & Video Quality
Editing & Converter
Live Stream
Installation
Watching TV
Stream Engine
Comparison Chart
ดาวน์โหลด
Firmware(Mac)
Firmware(Win)
Plugin(macOS)
Plugin(Win)
Assist Central
Utility(macOS)
Utility(Windows)
RECentral(Mac)
RECentral (Win)
Connect (Mac)
Connect (Win)
CamEngine(Chrome)
CamEngine(Mac)
CamEngine(Win)
เครื่องมือจัดการการดาวน์โหลด
Application(Windows)
Application(macOS)
แอปพลิเคชันและไดรเวอร์
เฟิร์มแวร์
Application
Utility & FW(Windows)
Utility & FW(macOS)
Utility (Chromebook)
ยูทิลิตี้
เครื่องมือเพื่อความเข้ากันได้
คู่มือฉบับย่อ
คู่มือผู้ใช้
เอกสารข้อมูล
Certificates
Date : 2019-10-18 00:00:00
- Version：RECentral v1.3.0.118
- OS：Win7 x86, Win7 x64, Win10 x86, Win10 x64
- Description：
Fixed Twitch login failed issue
Date : 2017-06-15 00:00:00
- Version：[Driver] v3.3.x.52
- OS：Win7 x86, Win7 x64, Win8.1 x86, Win8.1 x64, Win10 x86, Win10 x64
- Description：
1. Fix some minor issues.
Date : 2017-06-15 00:00:00
- Version：[Application] RECentral: v1.3.0.116
- OS：Win7 x86, Win7 x64, Win8.1 x86, Win8.1 x64, Win10 x86, Win10 x64
- Description：
1. Fix an issue that cannot stream to Twitch.
Date : 2018-06-05 00:00:00
- Version：[Driver] 3.3.x.78 (Beta)
- OS：Win7 x64, Win7 x86, Win8.1 x64, Win8.1 x86, Win 10 x86, Win 10 x64
- Description：
Fix 720p60fps not available at 3rd party applications (XSplit, OBS)
Date : 2017-06-16 00:00:00
- Description： English, Hrvatski, ภาษาไทย, Română, Türkçe, Polski, Česky, Magyar
Date : 2017-06-15 00:00:00
- Version：[Application & Driver] RECentral:1.3.0.116 Driver:3.3.x.52 (Beta)
- OS：Win7 x86, Win7 x64, Win8.1 x86, Win8.1 x64, Win10 x86, Win10 x64
- Description：1. Fixed Twitch crash issue.
Date : 2017-04-27 00:00:00
- Version：[Application & Driver] RECentral:1.3.0.115 Driver:3.3.x.52 (Beta)
- OS：Win7 x86, Win7 x64, Win8.1 x86, Win8.1 x64, Win10 x86, Win10 x64
- Description：1. Support AVerMedia mic devices.
Date : 2017-02-22 00:00:00
- Version：[Application & Driver] RECentral:1.3.0.112 Driver:3.3.x.52 (Beta)
- OS：Win7 x86, Win7 x64, Win8.1 x86, Win8.1 x64, Win10 x86, Win10 x64
- Description：1. Fixed windows desktop black screen when Open/Close setting wizard.
Date : 2016-10-14 00:00:00
- Version：[Application & Driver] RECentral:v1.3.0.109 (Beta) Driver:v3.3.x.52 (Beta)
- OS：Win7 x64, Win7 x86, Win8.1 x64, Win8.1 x86, Win 10 x86, Win 10 x64
- Description：A. update win10 logo driver
B. fixed youtube streaming fail if title or discription include Chinese
Date : 2016-09-23 00:00:00
- Version：[Application & Driver] RECentral:v1.3.0.109 (Beta) Driver:v3.3.x.52 (Beta)
- OS：Win7 x64, Win7 x86, Win8.1 x64, Win8.1 x86, Win 10 x86, Win 10 x64
- Description：1. Fixed youtube streaming fail with specific youtube user account
2. Fixed crash issue if "ASUS virtual camera" has been installed
3. Fixed sometimes recording or streaming be interrupted issue
4. Fixed twitch streaming fail issue
5. Fixed recording crash if mix mic at current pc mode
6. Fixed recorded file audio mute if change source audio sample rate when recording
7. Fixed sometimes crash when streaming
Date : 2016-02-19 00:00:00
- Version：[Driver] 3.3.x.52(Beta)
- OS：Win7 x64, Win7 x86, Win8.1 x64, Win8.1 x86, Win 10 x86, Win 10 x64
- Description：•Minor bug fixes and other improvements.
Date : 2016-02-19 00:00:00
- Version：[Application & Driver] RECentral:v1.3.0.104 (Beta) Driver:v3.3.x.52(Beta)
- OS：Win7 x64, Win7 x86, Win8.1 x64, Win8.1 x86, Win 10 x86, Win 10 x64
- Description：•Minor bug fixes and other improvements.
Date : 2016-01-14 00:00:00
- Version：Stream Engine v1.3.0.13 (Beta)
- OS：Win7 x86, Win7 x64, Win8.1 x86, Win8.1 x64, Win10 x86, Win10 x64
- Description：•The Live Gamer HD Stream Engine makes Live Gamer HD compatible with DirectShow compliant software (e.g., OBS, WireCast, FME...) by creating a virtual device called Live Gamer HD Stream Engine”.
•Simultaneously record the Live Gamer HD video source while streaming.
* Live Gamer HD driver must be pre-installed before running the Live Gamer HD Stream Engine.
Date : 2013-11-08 00:00:00
- Version：Stream Engine V1.0.0.3
- OS：Win 7 x86, Win 7 x64, Win 8 x86, Win 8 x64
- Description：•The Live Gamer HD Stream Engine makes Live Gamer HD compatible with DirectShow compliant software (e.g., OBS, WireCast, FME...) by creating a virtual device called ??ive Gamer HD Stream Engine??
•Simultaneously record the Live Gamer HD video source while streaming.
* Live Gamer HD driver must be pre-installed before running the Live Gamer HD Stream Engine.
Date : 2013-06-17 00:00:00
- Version：v22
- OS：Win 7 x86, Win 7 x64, Win 8 x86, Win 8 x64
- Description：•Support HDMI Color Range selection.
•Compatibility improved.
