D115SOXB/D115SONB

[Preliminary]

AI Box PC D115SOXB/D115SONB

Equips NVIDIA® Jetson™ Orin NX/Orin Nano Module

Embedded NVIDIA® Jetson Orin NX / Orin Nano
Supports super mode
2 x M.2. for WIFI and SSD
2 x GbE RJ-45 (Optional: Ethernet 1 supports PoE ; Ethernet 2 can be used for OOB management via NC-SI)
OOB for Power cycling and Cloud serial console (Optional)
1 x 5G daughter board for 4G/5G/capture card functions (Optional)
1 x HDMI output
20-pin expansion header
Operating temperature -25°C~60°C (TBD)
Dimension: W: 190mm x L: 175mm x H:80mm (TBD)

Overview

AVerMedia's AI Box PC D115SOXB / D115SONB equips powerful NVIDIA® Jetson Orin NX / Orin Nano module. This efficient system-on-module (SoM) opens new worlds of embedded IoT applications with full analytic capabilities.

D115SOXB/D115SONB is designed for the industry applications with spatial concern and feature a rich assortment of I/O ports for rapid AI-based solution development and seamless deployment as required by demanding business applications.

AVerMedia supports businesses of all sizes and offers customizable BSP services, flexible MOQ, in addition to NVIDIA’s JetPackTM SDK.

Stay Ahead with AVerCooler – Achieving 5°C Lower Operation under Others’ Regular Workload for Enhanced NVIDIA Jetson Efficiency, Extended Lifespan, and Superior Performance.

Key Industries

AVerMedia devices are built with flexibility in mind and are designed for the following verticals.

Smart Retail

Gather and deliver the information to streamline decisions and create more value for the customer.

Smart Camera

Smart cities rely on smart camera feeds to gain situational awareness and respond to real-time safety and security threats.

Smart City

Smart cities rely on live camera feeds to benefit from the video analysis to improve city operations fora variety of services.

Specifications

Model	D115SOXB-16G/D115SOXB-8G D115SONB-8G/D115SONB-4G
Type	Box PC
NVIDIA GPU SoC Module Compatibility	NVIDIA® Jetson Orin NX module (16GB / 8GB) NVIDIA® Jetson Orin Nano module (8GB / 4GB)
Super Mode	Support
Networking	2x GbE RJ-45 (Optional: Ethernet 1 for PoE* ; Ethernet 2 can be used with OOB for NC-SI function** ) 1xM.2. key E 2230 for wifi
Display Output	1 x HDMI output3840 x 2160 at 60Hz for Orin NX, 30Hzfor Orin Nano
Temperature	Operating temperature -25°C~60°C (TBD) Storage temperature -40°C ~ 85°C Relative humidity 40 °C @ 95%, Non-Condensing
MIPI Camera Inputs	2x 4 lane MIPI CSI-2, 22 pin FPC 0.5mm Pitch Connector
USB	1x USB 2.0 type C for recovery 2x USB 3.2 Type-A (Native 10Gbps per port)
Storage	1x M.2. key M 2280 for NVMe (256G SSD installed in box PC)
Expansion Header (Internal)	20 pins: 2x I2C, 2x UART, 4x GPIOs, 1xCAN (EU terminal block)*** 15-pin & 10-pin: Supports OOB management via OOB module (optional, sold separately) 40-pin wafer: Supports 4G/5G/capture card functions via daughter board (optional, sold separately)
Security	TPM 2.0 supported
Input Power	DC in JACK on board & ATX 4pin 12V/5A, 12V~24V is recommended.
Power Cord	US/JP/EU/UK/TW/AU/CN
Fan Module	Fanless Solution
Buttons	Power and Recovery
RTC Battery	Support RTC battery and Battery Life Monitoring by MCU
PCB/Electronics Mechanical Info	Operating temperature -25°C~45°C: 190mm (W) x 175mm (L) x 80mm (H) (TBD) Operating temperature -25°C~60°C: 190mm (W) x 200mm (L) x 80mm (H) (TBD) Weight: 2kg (TBD)
Certifications	CE, FCC, VCCI,KC (TBD)
Package	1x D115SOXB/D115SONB (256G SSD installed) 1x Adapter and Power cable

Ordering Information

Model	SKU Number	NVIDIA SOM	SSD	PSE board*	OOB Module** [Preliminary]	5G Daughter Board [Preliminary]	Mechanical Info
D115WOXB	D115WOXB-16G-001	Orin NX 16G	256G	-	-	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1kg
D115WOXB	D115WOXB-16G-002	Orin NX 16G	256G	YES	-	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.1kg
D115WOXB (5G)	D115WOXB-16G-003	Orin NX 16G	256G	-	NC-SI Function (Eth)	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WOXB-16G-004	Orin NX 16G	256G	YES	NC-SI Function (Eth)	-	•W: TBD •Weight: TBD
D115WOXB (5G)	D115WOXB-16G-005	Orin NX 16G	256G	-	RMII Function (Eth)	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WOXB-16G-006	Orin NX 16G	256G	YES	RMII Function (Eth)	-	•W: TBD •Weight: TBD
D115WOXB (5G)	D115WOXB-16G-007	Orin NX 16G	256G	YES	-	4G Module	•W: TBD •Weight: TBD
D115WOXB (5G)	D115WOXB-16G-008	Orin NX 16G	256G	YES	-	5G Module	•W: TBD •Weight: TBD
D115WOXB (5G)	D115WOXB-16G-009	Orin NX 16G	256G	YES	-	Frame Grabber CN312SW	•W: TBD •Weight: TBD
D115WOXB (5G)	D115WOXB-16G-010	Orin NX 16G	256G	YES	-	Frame Grabber CN312M	•W: TBD •Weight: TBD
D115WOXB (5G)	D115WOXB-16G-0011	Orin NX 16G	256G	-	4G module	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WOXB-8G-0012	Orin NX 8G	256G	-	4G module	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WONB (5G)	D115WONB-8G-0013	Orin Nano 8G	256G	-	4G module	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WONB (5G)	D115WONB-4G-0014	Orin Nano 4G	256G	-	4G module	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WOXB-8G-0015	Orin NX 8G	256G	-	NC-SI Function (Eth)	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WOXB-8G-0016	Orin NX 8G	256G	-	RMII Function (Eth)	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WONB-8G-0017	Orin Nano 8G	256G	-	NC-SI Function (Eth)	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WONB-8G-0018	Orin Nano 8G	256G	-	RMII Function (Eth)	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WONB-4G-0019	Orin Nano 4G	256G	-	NC-SI Function (Eth)	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115WOXB (5G)	D115WONB-4G-0020	Orin Nano 4G	256G	-	RMII Function (Eth)	-	•126mm x 96mm x 73.9mm (4.96” x 3.78” x 2.91”) • weight : 1.3kg
D115SOXB	D115SOXB-16G-001	Orin NX 16G	256G	-	-	-	•190mm x 175mm x 80mm (7.48” x 6.89” x 3.15”) • weight : 2kg (TBD)

*With the optional OOB module, the default configuration uses Ethernet 2 on the D115W for OOB management, rendering the OOB-Ethernet on the OOB module inactive. Alternatively, we offer another option that allows users to manage via the Ethernet on the OOB module, changing the box PC configuration from 2 RJ45 ports to a total of 3 RJ45 ports, including the RJ45 on the OOB module.

Optional Accessories

Optional Accessories	Specs
MIPI Camera	For 22pin MIPI connector: 1. raspberry pi camera v2 /raspberry pi camera v3 2. Manufacturer: APPRO.PHO ■ B-04: IMX179 (8M) MIPI, 1080P (30fps)

Specs

MIPI Camera

For 22pin MIPI connector:

1. raspberry pi camera v2 /raspberry pi camera v3

2. Manufacturer: APPRO.PHO

■ B-04: IMX179 (8M) MIPI, 1080P (30fps)

* For details, please refer to the "Accessory-PoE Board" webpage.

** For details, please refer to the "Accessory-OOB module" webpage. Ethernet 2 supports NC-SI for enabling Allxon OOB and In-Band functions simultaneously.

***When equipped with the OOB module, 2x UART will be unavailable.

****Please contact your local sales for more information. All specifications are subject to change without prior notice.

Orin Box PC

OS	Version	Compatible SoMs	Release Note
L4T r36.4.3 (Jetpack 6.2)	AVERMEDIA_JETPACK-R1.1.4.6.2.0 (Beta)	AGX Orin Orin NX & Orin Nano Orin Nano Super Mode Orin NX Super Mode	ReadMe

OS	Version	Compatible SoMs	Release Note
L4T r36.4.3 (Jetpack 6.2)	AVERMEDIA_JETPACK-R1.1.0.6.2.0 (Beta)	AGX Orin Orin NX & Orin Nano Orin Nano Super Mode	ReadMe
