OOB Module

[Preliminary]

The Out-of-Band (OOB) management of OOB Board is a complete solution that provides remote device management services.

Applications:

- Power cycling

- Cloud serial console

- M.2. B key slot for 4G module (optional)

- Expansion function: Thermo-guard/SSD backup & recovery (optional)

Overview

Conquer the final challenge of your edge AI projects: seamless deployment and scalable management. The Out-of-Band (OOB) management of OOB Board is a complete solution that provides remote device management services.

In the event of an edge system malfunction and subsequent shutdown, the OOB function can be utilized to power the system back on and verify whether the device has resumed normal operations.The OOB Board offers customers a customizable cloud-based device management portal for easily controlling all edge devices remotely.

Specifications

Model	OOB Module
Applicable product	D133	D115W	D135	D131/D131L	D315 / D315 5G / D315AOP
System	Nuvoton NUC980
External I/O	•1 x RJ45 10/100Mb (LED indicator) •1 x Micro SIM slot for 4G module*
Internal I/O	•1 x 15pin wafer for PWB、RST、5V、3V3、 Sys Debug UART、I2C、auto- link UART、 Power detecting pin、 GPIO •1 x 10pin wafer for NCSI (supported by D115W & D135) •1 x reset button •1 x DIP switch for function setting •1 x USB type-C for MCU update •1 x 2pin wafer for SSD recovery (TBD)			•1 x 15pin wafer for PWB、RST •1 x reset button •1 x DIP switch for function setting •1 x USB type-C for MCU update •1 x 2pin wafer for SSD recovery (TBD)***
Expansion	•1 x M.2 Key. B 3042 (only USB2.0) for 4G module*			NA
Power Input	5V power					3V3 power
Environment	•Operating temperature -40°C ~ 85°C (TBD, The actual situation depends on the box PC spec. ) •Storage temperature -40°C ~ 85°C
Mechanical	55 x 56.2mm
Package	•OOB Board •Cable •Screws

* We will support this feature upon customer request.

**The 10pin wafer on D131/D131L/D315 doesn't support NCSI.

*** The 2-pin wafer is for Apacer's SSD recovery function.

**** All specifications are subject to change without prior notice.
