Fanless design to prevent dust accumulation
1x GbE & 1x 10G RJ-45
10GigE Vision camera connector
1x PCIe slot for multi-function expansion
1x mPCIe for 4G & 5G with adapter card
1x M.2. E key for Wi-Fi 6E
1x M.2. M key for SSD and capture
Operating temperature D315AOP 32G: -25°C ~50°C
Operating temperature D315AOP 64G: -25°C ~40°C
Dimension (Fanless): 160*136.9*65mm
Weight: 1.55kg
AVerMedia's AI Box PC D315AOP equips powerful NVIDIA® Jetson AGX Orin™ 32G or 64G module , which brings next-level AI performance and power-efficient capability for all autonomous machines. This efficient SoM makes advanced analytics possible while providing the ability to handle a host of other embedded IoT applications.
D315AOP features a 120-pin high-speed connector designed for connecting MIPI SerDes cameras, catering to the needs of AMRs (please note that the adapter board and MIPI camera are not included). In addition, a sufficient Ethernet bandwidth with 10G is excellent for applying smart security, enabling dozens of IP cameras to stream simultaneously. The connector for the 10GigE Vision Camera is also great for smart inspection. Lastly, with its compact size, D315AOP furnishes a PCIe slot for multi-function expansion and excellent compatibility with Wi-Fi 6 and 5G.
AVerMedia devices are built with flexibility in mind and are designed for the following verticals.
AMRs deployment relies on live camera feeds to provide a rapid and flexible adjustment for the working process and creates a significant productivity growth.
Smart security relies on live camera feeds to benefit from the video analysis to improve and ensure community safety.
Smart inspection relies on live camera feeds to benefit from fast and accurate detection to improve quality control in production.
Model | D315AOP |
|---|---|
NVIDIA Jetson SoM | NVIDIA® Jetson AGX Orin (32G / 64G) module |
Networking | 1x GbE RJ-45 1x 10G RJ-45 |
Display Output | 1x HDMI 2.0 (3840x2160 at 60Hz) |
Temperature | Operating temperature D315AOP 32G: -25°C~50°C Operating temperature D315AOP 64G: -25°C~40°C Storage temperature: -40°C ~ 85°C Relative humidity: 40 °C @ 95%, Non-Condensing |
USB | 1x USB 2.0 Micro-B for recovery 2x USB 2.0 Type-A 2x USB 3.2 Type-A |
Audio | Intel HD Audio analog connector |
Storage | 1x micro-SD card slot |
Expansion Header | 40-pin (UART, SPI, CAN, I2C, I2S, GPIOs) 1x mPCIe for 4G & 5G with adapter card 1x M.2 E key (for Wi-Fi 6E) 1x M.2 M key (for SSD or AVerMedia capture card:CN311-H, CN312SW, CN312MW)、1x Micro SIM socket 1x PCIe x16 (only support x8 PCIe lanes) 1x CAN bus with transceiver, 120-pin (for MIPI SerDes*) *The adaptor board is not included but can be customized by project. Please contact our sales team for more infomation. |
Input Power | DC in jack on board: 54V/2.78A adapter DC Range 12~54V (7~1.95A) ATX 4-pin: 12~54V (10.8~2.4A) |
Power Cord | US/JP/EU/UK/TW/AU/CN |
Thermal Solution | Fanless solution |
Buttons | Power and Recovery |
RTC Battery | Support RTC Battery and Battery Life Monitoring by MCU |
Dimensions | 160mm * 136.9mm * 65mm |
Certifications | CE, FCC, VCCI, KC |
Package | 1x D315AOP 1x Adapter 54V/2.78A and Power cord |
Wi-Fi Module | M.2 M key 2230 | Intel® Wireless-AC 9260、Intel® Wi-Fi 6E AX210 | |||
|---|---|---|---|---|---|
SSD | M.2 M key 2280 | 256GB | |||
Capture Card | M.2 M key 2280 | CN312MW | 1x SDI; 1x HDMI | 2Kp60 in (SDI), 1920 x 1200p60 in (HDMI),1080p out | |
M.2 M key 2280 | CN312SW | 2x SDI | 2Kp60 in - 1080p out | ||
M.2 M key 2280 | CN311-H | 1x HDMI | 4096 x 2160p30 in and out | ||
Date : 2024-06-13 00:00:00
Date : 2024-05-29 00:00:00
| OS | Version | Release Note |
| L4T 35.4.1 (Jetpack 6.0) | D315AO-R3.1.0.6.0.0 (BETA) | ReadMe |
Date : 2024-05-28 00:00:00
| OS | Version | Release Note |
| L4T 35.4.1 (Jetpack 5.1.3) | D315AO-R2.5.2.5.1.3 | ReadMe |
