Frame Grabber-PCIe - CL314H1

Overview Download
Where to Buy

CL314H1

1080p60 HDMI 4-Channel Low Profile Video Frame Grabber

  • Maximum input resolution up to 4096×2160/30fps

  • Maximum capturing and recording up to 2-ch 4096×2160/30fps

  • Low-profile PCI Express form factor

  • Reduce the capture latency to shorten the time required for a full frame of image to be captured

  • Support hardware up/down scaling, de-interlacing, and color space convert

  • Support 10-bit color depth

  • For 2-channel model: CL312H1

Overview



AVerMedia CL314H1, the 1080p60 HDMI 4-Channel low profile video capture card, is equipped by four HDMI channels with the embedded audio input and supports astounding uncompressed real-time video capturing up to 1920 x 1080 60fps full HD resolution.


At the frame rate of 60 fps, CL314H1 can improve the quality of a wide range of media recorded for businesses, universities, broadcasting, and manufacturing facilities, which can eventually provide a more lifelike and smooth video playback experience.

Hardware scaling, de-interlacing, and color space conversion

With the AVerMedia Video Engine Technology inside, it can perform various video processing tasks such as frame rate conversion, hardware up/down scaling, de-interlacing, and so on without consuming the computing power of the target platform.

Improved Quality and Reliability



With the powerful FPGA-based design, the CL314H1 is able to achieve a better performance and provide more improved capture quality and reliability.

Low Profile Form Factor



Suitable for small-footprint embedded platform, the compact low profile form factor design provides a better use of internal space and reduces cable routing. It increases the use of interior space for a more flexible heat spreading solution.

Hardware Video Processing



CL314H1 has built-in AVerMedia Video Engine technology which implements most useful video enhancing features to significantly reduce the efforts of CPU and the software development. In other words, this can help our clients to achieve the better cost saving of the hardware platform and the development resource.

Support up to 4:4:4 10-bit RGB and YUV

The 10-bit color depth support is especially useful in the medical imaging applications where images with the slightest color variation may indicate different conditions or stages of diseases. This in turn may assist doctors in accurately diagnosing patient conditions.

Versatile AVerMedia SDK

Industrial customers can develop vertical applications flexibly and efficiently by using AVerMedia’s exclusive designed SDK with features such as device control, media capture, A/V processing and more.

Learn more about AVerMedia SDK.

Main/Daughter Board Design



Our CL314H1 low-profile ready capture card come with a smaller bracket as well, so you can choose to install it on a regular or low-profile system.

Specifications

Model

CL314H1

Host Interface

PCIe Gen2 x 4

Audio Interface

HDMI embedded PCM

Audio Format

Embedded HDMI, PCM

Audio Sampling Rate

32/44.1/48KHz

Connector Type

HDMI Type A

Input Interface

HDMI*4 (HDMI 1.4a)

Video Format

YUV444: IYU2, AYUV, V410, Y410

YUV422: YUY2, YUYV, UYVY, V210, Y210

YUV420: I420, NV12, YV12

RGB: RGB565, RGB555, RGB24, RGB32, ARGB

Color Depth

8 bit/10bit

Channel No.

4 channels

Max. Input Resolution

4096x2160 30fps

Max. Recording Resolution

4096x2160 30fps (2ch)

1920x1080 60fps (4ch)

Encoding Mode

Software Encoding

Multi-Card Support

Yes

Supported OS

Windows 7, 8.1, 10 (32/64-Bit) Linux Kernel 2.6.14 and above (32/64-bit)

Form Factor

PCIe Low Profile

Dimension (L x W)

180 x 68.78 mm

Power Consumption

15W<

Operating Temperature

0°C ~ 50°C

Operating Humidity

5% - 80% Relative Humidity

Safety Certification

FCC / CE

*All specifications are subject to change without prior notice.

DOWNLOAD

Source code
3D drawing
Datasheet
Driver
User Manual
BSP for Nano
BSP for NX
BSP for TX2 NX
SDK and Capture Studio
BSP

Date : 2021-12-24 00:00:00

Version: AVerMedia SDK v1.2.1.65 & Capture Studio v1.5.1.56
OS: Win7/8.1/10 x86 and x64, Win11 x64
Description: Support Win11

Date : 2020-08-27 00:00:00

Version: AVerMedia SDK v1.2.1.55 & Capture Studio v1.5.1.45
OS: Win7/8.1/10 x64、x86
Description: 1. Update SDK DLL v4.2.1.50
                          2. Update HTTP sink filter

Date : 2018-12-25 00:00:00

Version: AVerMedia Capture Studio 1.5.1.11 (BETA)
OS: Win7/8.1/10 x64、x86
Description: 1. update Videoprocess filter v2.3.9.1;avernvenc_x64.ax v2.0.0.6
                          2. update sdk dll v4.2.1.16

Date : 2018-12-25 00:00:00

Version: AVerMedia SDK 1.2.1.17 (BETA)
OS: Win7/8.1/10 x64、x86
Description:
1. update Videoprocess filterv2.3.9.1
2. update avernvenc_x64.ax v2.0.0.6 for record 4K NVENC
3. fix audio bitrate value of MPEG&MP4 RecordConfig.ini
4. update the resolution of CL314_H1
5. capture image not support clip& ovlay when color sapce is RGB24
6. fixed bug:wrong information of input source
7. fixed bug: PlayBack SDK cannot play MP4&TS file

Date : 2021-02-23 00:00:00

Version: [Linux Driver] 2.0.8
OS: Ubuntu 20.04/18.04/16.04 kernel 5.4.0-4.15.0
        TegraOS kernel 4.4.0
Description: Support users to complie driver by themselves

Date : 2020-08-27 00:00:00

Version: [Driver] 8.0.64.44
OS: Win7/8.1/10 x64
Description: 1. Improved performance (it must update FPGA to 19110501)
                          2. Fix audio crackling on Win10 2004 (it must update FPGA to 19110501)
                          3. Improved video scaler quality
                          4. Improved compatibility with 3rd party application

Date : 2020-08-27 00:00:00

Version: [Driver] 8.0.0.44
OS: Win7/8.1/10 x86
Description: 1. Improved performance (it must update FPGA to 19110501)
                          2. Fix audio crackling on Win10 2004 (it must update FPGA to 19110501)
                          3. Improved video scaler quality
                          4. Improved compatibility with 3rd party application

Date : 2019-06-19 00:00:00

Product Datasheet
Show More
×
