Frame Grabber-Mini - CM313BW

Overview Download
Where to Buy

CM313BW

1080p60 H.264 H/W Encode Mini PCIe Video Capture Card

  • Supports extended operating temperatures from -40° to 85°C

  • H.264 H/W encoding Mini-PCIe

  • HD video capture with 3G-SDI input

  • Low latency uncompressed video/audio and H.264 transport stream outputs

  • Supports AES embedded audio inputs

Overview



The CM313BW is a Mini PCIe HW encode video capture card which supports a single 3G-SDI input providing a nominal 2.970 Gbit/s interface for applications requiring HD 1080p video resolution. The CM313BW enables professionals to capture SD, HD, or 3G-SDI video footage in real-time 3G-SDI Video Input. The CM313BW offers stable operation in extreme environments under temperatures ranging from -40°C to 85°C (-40°F to 185°F).



Designed with 3G-SDI standards (SMPTE 424M), the CM313B offers uncompressed, H.264 digital video signal transmission, including embedded audio and supports input resolution up to 1920 x 1080 60fps. The SDI standard provides a nominal 2.970 Gbit/s interface specifically suited for applications such as in-vehicle, broadcasting, and surveillance.

Extended Temperature



AVerMedia delivers extended temperature solutions capable of withstanding extreme environmental conditions without compromising functionality. The extended temperature capture card line operates within temperature ranges of -40°C to 85°C (-40°F to 185°F). The thermally robust product line is specifically designed to provide greater flexibility for rugged and industrial applications, including: medical, industrial automation, factory automation, in-vehicle, and more.



AVerMedia guarantees that our products are made in accordance with the highest standards, ensuring a wide temperature range, design compactness, durability, high performance, and extended life cycles. Our design and testing procedures meet these requirement through the use of extended-temperature-grade components, onboard soldering of critical components, detailed engineering designs for wide temperature ranges, and certified testing under harsh conditions.

Dual Data Output Formats



CM313BW Mini PCIe video capture card supports real time mega pixel video images from any standard 3G-SDI onto a computer. Enabling professionals real-time streaming, video production and post production of live uncompressed 8-bit SDI SD-, HD- and 3G-SDI capturing up to 1920 x 1080. Featuring dual data output formats, the CM313BW can simultaneously uncompressed raw data and compress H.264 HW TS maintaining a low CPU loading.

Versatile AVerMedia SDK

Industrial customers can develop vertical applications flexibly and efficiently by using a specifically designed SDK, with features such as device control, media capture, A/V processing, and more.


Learn more about AVerMedia SDK.

Specifications



Model

CM313BW

Interface

Mini PCI-e

Channel No.

1

Max. Resolution

1920x1080

Frame Rate

24p, 25p, 30p, 50p, 60p, 50i, 60i

Color Format

YUY2(4:2:2), YV12 (4:2:0), RGB24

Color Depth

8 bit

Supported OS

Windows 7/8.1/10 (32/64 bits), Linux (32/64 bits)*

SDK Supported Language

C, C++, C#, VB, VB.net, Delphi

H/W Encode Format

H.264/AAC

Audio Input

SDI (embedded audio)

Operating Temperature

Temperature:-40°C to 85°C (-40°F to 185°F)

Humidity: 0 to 90% RHNC

Storage Environment

Temperature: -50°C to +100°C

Humidity: 0 to 90% RHNC

Dimensions (L x W)

50.95 x 30mm

*All specifications are subject to change without prior notice.

** Linux Services
‧ For driver availability, please contact support
‧ Driver customization service by request

DOWNLOAD

Datasheet
Driver
User Manual
BSP for Nano
BSP for NX
BSP for TX2 NX
SDK and Capture Studio
BSP

Date : 2021-12-24 00:00:00

Version: AVerMedia SDK v1.2.1.65 & Capture Studio v1.5.1.56
OS: Win7/8.1/10 x86 and x64, Win11 x64
Description: Support Win11

Date : 2020-06-30 00:00:00

Version: [Linux Driver] 1.5.0600
OS: Ubuntu 20.04/18.04/16.04 kernel 5.4.0-4.10.0
Description: Support users to complie driver by themselves

Date : 2017-09-08 00:00:00

Version: 3.4.x.86
OS: Win 7 x64, Win 8.1 x64, Win 10 x64
Description: Win10 RS2 WHQL

Date : 2017-09-08 00:00:00

Version: 3.4.x.86
OS: Win 7 x86, Win 8.1 x86, Win 10 x86
Description: Win10 RS2 WHQL

Date : 2019-07-12 00:00:00

Product Datasheet
