Frame Grabber-PCIe - C725B

Overview Download
Where to Buy

C725B

SD PCIe Frame Grabber

  • Fully DirectShow compatible

  • Supports uncompressed video capture for AVI or WMV formats

  • Supports snapshots for BMP or JPG formats

  • Captures and digitizes NTSC/PAL/SECAM analog signals

  • Supports multiple programming languages

Overview



The AVerMedia EZMaker SDK Express (C725B) is a PCI-E video capture card equipped with composite, S-Video and stereo audio inputs for digitizing video from analog signals into uncompressed AVI format at 25/30 fps for a wide range of resolutions. It supports PAL, NTSC and SECAM video standards, and also comes with a software development kit that includes frequently used applications to allow system developers to integrate apps in various operating platforms.



The AVerMedia EZMaker SDK Express guarantees fast response and solid performance with its advanced hardware design and customizable software development kit, while also promising a user-friendly user experience. Featuring S-Video, composite and stereo audio inputs, the EZMaker SDK Express allows you to record video from various device sources and digitize it at optimal quality resolution.



The EZMaker SDK Express supports NTSC, PAL and SECAM video standards, ensuring flexibility and capability in capturing content from a wide range of video sources. AVerMedia also includes a comprehensive, powerful SDK kit that works with multiple programming languages to help you easily build the features you need

Connection Diagram

Specifications

Model

C725B

Host Interface

PCIe

Input

S-Video

Composite (RCA)

Audio (L/R)

Input Video Resolution

160 × 120, 176 × 144, 240 × 180, 240 × 176
320 × 240, 352 × 240, 352 × 288 (PAL only)
640 × 240, 640 × 288, 640 × 480
704 × 576 (PAL only), 720 × 240, 720 × 288
720 × 480, 720 × 576 (PAL only)

Capture Video format

NTSC: 720 x 480, PAL: 720 x 576

Pixel Format

YUY2(4:2:2), UYVY (4:2:2), RGB24 (4:4:4)

Color Adjustment

Brightness, Contrast, Hue, Saturation, Sharpness

Multi-Card Support

Yes (up to 8 pcs)

Programming Language

Visual Basic, Visual C++, Delphi, C#, VB.NET

SDK Framework

General DLL

Operating Environment

Temperature: 0 to +65 ℃
Humidity: 15 to 80% RHNC

Storage Environment

Temperature: -30 to +65 ℃
Humidity: 15 to 90% RHNC

Power Requirement

3.3V max 400mA

Dimensions (L x W)

93.5 x 68.78mm

CPU

Intel® Pentium® 4 3.0 GHz

AMD Athlon™ 64 3200+

Memory

512 MB RAM

VGA

VGA card with support for DirectX9.0c or above

Supported OS

Windows 7/ 8.1/ 10 (32/ 64 bits)*

Sound Card

Yes

*All specifications are subject to change without prior notice.
‧ For driver availability, please contact support
‧ Driver customization service by request

DOWNLOAD

Datasheet
Driver
User Manual
BSP for Nano
BSP for NX
BSP for TX2 NX
SDK and Capture Studio
BSP

Date : 2021-12-24 00:00:00

Version: AVerMedia SDK v1.2.1.65 & Capture Studio v1.5.1.56
OS: Win7/8.1/10 x86 and x64, Win11 x64
Description: Support Win11

Date : 2021-12-24 00:00:00

Version: [Windows Driver] 10.2.x.116
OS: Win10 x86/Win10 x64
Description: Win10 WHQL

Date : 2013-10-21 00:00:00

Product Datasheet
